2 Pack JD1914 Car Relay, 12V 40A, 5 Pin SPDT, Automotive Switches and Starters,

$ 5.09

Coil Voltage: 12.0 Input Voltage: 12.0 Current Rating: 40.0 Item Package Quantity: 2 Included Components: Jd1914 1C3G Measurement System: Number Weight: 0.18 Pounds Lower Temperature Rating: -40.0 Contact Material: Silver Alloy Specification Met: Ce Operation Mode: Automatic Minimum Switching Voltage: 12.0 Model Number: Jd1914 1C3G material: Silver Alloy Wattage: 1600.0 Part Number: 820-012-1C3G Operating Voltage: 12.0 Contact Type: Normally Closed, Normally Open Brand: Weasch Connector Type: Plug-In Package Dimensions LxWxH: 3.54x1.97x1.57 Inches Mounting Type: Plug In Mount model: Jd1914 1C3G

Description

2 Pack JD1914 Car Relay, 12V 40A, 5 Pin SPDT, Automotive Switches and Starters,. Insulation Resistance: ≤ 100MΩ. Contact Ratings Contact Form: SPDT Material: AgSn02 Max.Operating Current: 40A Coil Ratings Rated Voltage: 12VDC Nominal Operating Power: 1.6W Specification Insulation Resistance: ≤ 100MΩ Dielectric Strength(Between coil and Contact): 500VAC Ambient Temperature: -40℃ ~125℃ Operate/Release Time: 10ms/10ms (min)Mechanical Life: 1000000 (min)Electrical Life: 100000 Product Name: Car Relay; Model: JD1914Rated Voltage: 12VDC; Max.Operating Current: 40AContact: SPDT; Number of Pins: 5Contact Material: Ag Alloy; Insulation Resistance: ≤ 100MΩPackage Content: 2 x JD1914 Car Relay
