Cisco Nexus 3172TQ 48 Port 10 Gigabit Switch 6x 40G QSFP+ N3K-C3172TQ-10GT #2

Description

Cisco Nexus 3172TQ 48 Port 10 Gigabit Switch 6x 40G QSFP+ N3K-C3172TQ-10GT #2. Nexus 3172TQ (N3K-C3172TQ-10GT). 6x 40 Gigabit QSFP+. 48x 10 Gigabit RJ-45 Ethernet (10GBase-T). bootflash: 1990656 kB. cisco Nexus 3172T Chassis ("48x10GT + 6x40G Supervisor"). Switch has been reset to factory defaults. Cosmetic Condition: C3 - Used Fair Functional Condition: F4 - Hardware Functional Data Sanitization: ND - Non-Data Make: Cisco Model: Nexus 3172TQ (N3K-C3172TQ-10GT) Ports: 48x 10 Gigabit RJ-45 Ethernet (10GBase-T) 6x 40 Gigabit QSFP+ PoE Specs: N/A Rack Size: 1U Power Supply: 2x NXA-PAC-500W (Takes C13 Plug) Defects: Signs of paint loss / discoloration towards the back of the top face. Some scratching, scuffing, and other general signs of prior use, see photos. Missing Components: Power Cord(s) Notes: Switch has been reset to factory defaults. The unit comes with NX-OS 6.0(2)U3(4) installed. Command Output: switch# show env Fan: ------------------------------------------------------ Fan Model Hw Status ------------------------------------------------------ Fan-1 N3K-C3072-FAN -- ok Fan-2 N3K-C3072-FAN -- ok Fan-3 N3K-C3072-FAN -- ok Fan-4 N3K-C3072-FAN -- ok PS-1 NXA-PAC-500W -- ok PS-2 NXA-PAC-500W -- ok Temperature ------------------------------------------------------------------------- Module Sensor MajorThresh MinorThres CurTemp Status (Celsius) (Celsius) (Celsius) ------------------------------------------------------------------------- 1 ASIC 110 100 46 ok 1 Front-Left (D1) 68 60 26 ok 1 Front-Right(D2) 64 56 25 ok 1 Back (D3) 55 46 22 ok Power Supply: Voltage: 12 Volts ----------------------------------------------------------- PS Model Input Power Current Status Type (Watts) (Amps) ----------------------------------------------------------- 1 NXA-PAC-500W AC 504.00 42.00 ok 2 NXA-PAC-500W AC 504.00 42.00 ok Mod Model Power Current Power Current Status Requested Requested Allocated Allocated (Watts) (Amps) (Watts) (Amps) --- ---------------------- ------- ---------- --------- ---------- -------- -- 1 N3K-C3172TQ-10GT-SUP 349.20 29.10 349.20 29.10 powered- up Power Usage Summary: -------------------- Power Supply redundancy mode: Redundant Power Supply redundancy operational mode: Redundant Total Power Capacity 1008.00 W Power reserved for Supervisor(s) 349.20 W Power currently used by Modules 0.00 W ------------- Total Power Available 658.80 W ------------- switch# show license default Feature Default License Count ------------------------------------------------------------------------------- LANBASESERVICESPKG - ALGOBOOSTSERVICESPKG - LANENTERPRISESERVICESPKG - ------------------------------------------------------------------------------- switch# show ver Cisco Nexus Operating System (NX-OS) Software TAC support: http://www.cisco.com/tac Documents: http://www.cisco.com/en/US/products/ps9372/tsdproductssupportserie shome.html Copyright (c) 2002-2014, Cisco Systems, Inc. All rights reserved. The copyrights to certain works contained herein are owned by other third parties and are used and distributed under license. Some parts of this software are covered under the GNU Public License. A copy of the license is available at http://www.gnu.org/licenses/gpl.html. Software BIOS: version 2.0.0 loader: version N/A kickstart: version 6.0(2)U3(4) system: version 6.0(2)U3(4) Power Sequencer Firmware: Module 1: version v1.1 BIOS compile time: 04/01/2014 kickstart image file is: bootflash:///n3000-uk9-kickstart.6.0.2.U3.4.bin kickstart compile time: 10/10/2014 10:00:00 [10/10/2014 19:33:20] system image file is: bootflash:///n3000-uk9.6.0.2.U3.4.bin system compile time: 10/10/2014 10:00:00 [10/10/2014 21:21:47] Hardware cisco Nexus 3172T Chassis ("48x10GT + 6x40G Supervisor") Intel(R) Pentium(R) CPU @ 2.00GHz with 3912752 kB of memory. Processor Board ID FOC21090X3R Device name: switch bootflash: 1990656 kB Kernel uptime is 0 day(s), 0 hour(s), 7 minute(s), 13 second(s) Last reset Reason: Unknown System version: Service: plugin Core Plugin, Ethernet Plugin switch# show inv NAME: "Chassis", DESCR: "Nexus 3172T Chassis" PID: N3K-C3172TQ-10GT , VID: V01 , SN: FOC2106R264 NAME: "Module 1", DESCR: "48x10GT + 6x40G Supervisor" PID: N3K-C3172TQ-10GT , VID: V01 , SN: FOC21090X3R NAME: "Fan 1", DESCR: "Chassis fan module" PID: N3K-C3072-FAN , VID: N/A , SN: N/A NAME: "Fan 2", DESCR: "Chassis fan module" PID: N3K-C3072-FAN , VID: N/A , SN: N/A NAME: "Fan 3", DESCR: "Chassis fan module" PID: N3K-C3072-FAN , VID: N/A , SN: N/A NAME: "Fan 4", DESCR: "Chassis fan module" PID: N3K-C3072-FAN , VID: N/A , SN: N/A NAME: "Power supply 1", DESCR: "AC power supply" PID: NXA-PAC-500W , VID: V01 , SN: LIT16490YAP NAME: "Power supply 2", DESCR: "AC power supply" PID: NXA-PAC-500W , VID: V01 , SN: LIT183108BF switch# Disclaimer: Unless otherwise specified, this item is used and may have some discoloration, scuffing, scrapes, permanent markings or sticker residue. We will do our best to mention these flaws in the description area of the listing. Our items are government and corporate surplus. We have a limited knowledge of their prior use. Please be aware there is always a risk involved when purchasing anything in used or pre-owned condition. As such we make absolutely no guarantee as to how long this item or any components within this item will continue to function after purchase. In addition, while we make our best effort to test all items thoroughly, there may be problems or defects that were not discovered during the testing process. No partial refunds. Please contact us through eBay's messaging system with any questions or concerns. Payment: Payment is due within 4 days. If payment is not received within 4 days we reserve the right to cancel your order on the 5th day per eBay policy. Please contact us if something comes up. We will gladly work with you to figure out a solution best for both parties. Please contact us through eBay's messaging system with any questions or concerns. Shipping: All items are shipped FEDEX, UPS or USPS unless otherwise noted. Insurance is included in the shipping price. Higher priced items will require a signature ($500 or more). No exceptions. We can only ship to the address you provide on the eBay checkout page. Once the item is paid for, we can not change the shipping address. Please note some lighter items may be shipped out using USPS First Class. Items are shipped within 1-2 business days (excluding weekends and most major US holidays). Tracking numbers are sent out when the item is shipped. You will get an email from eBay. You can access your tracking info at any time in your My eBay page. Please check spam filters before contacting us about where your tracking number is. We only ship to the lower 48 United States. We do not ship to P.O. Boxes. Please contact us through eBay's messaging system with any questions or concerns. Returns: We currently offer a free 30-day return policy. The item must be returned in the condition it was received. This means you must package the item up in the same way it was sent. We reserve the right to refuse returns or withhold up to 50% of the purchase price as per eBay policy. All items sold in lots must be returned in whole. We do not offer partial refunds on lots. We are sorry for any inconvenience this may cause. If the item is Local Pickup, the buyer would have to arrange the return of the item. We do not offer partial refunds. If there is an issue with the order, it will have to be sent back. In the case of a return involving a purchase that was sent to a freight forwarder and shipped outside of the US, the buyer is responsible for all shipping costs. Please contact us through eBay’s messaging system with any questions or concerns. Contacting Us: If you have any questions or concerns about an order please contact us through the eBay messaging system. Our business hours are: Monday to Friday 8:00AM to 3:30PM ET. We are closed on the weekend and on most major US holidays. If you contact us outside of these hours we will get back to you the following business day.
