Eaton XTRM10A22TD XT Control Relay, 4PST-2NO / 2NC Contact Configuration, 24VDC
$ 24.57
Description
Eaton XTRM10A22TD XT Control Relay, 4PST-2NO / 2NC Contact Configuration, 24VDC. IEC Mini Control Relay, Current Rating 10 A, Contact Form 2NO/2NC, Contact Rating (DC) 2.5 A @ 24V, Coil Voltage 24V DC, Contact Rating (AC) 6 A @ 240V, Relay Style IEC, Electrical Connection Screw Terminal, Mounting Style DIN Rail, Power Consumption 2.6 W, IP Rating IP20, Frame Size 45 mm, NEMA Size Not Applicable, Compatible with Series XTRM Mini Control Relays, Maximum Operating Temperature 122 Degrees F, Frequency 60 Hz, Body Depth 2.05 in, Body Height 2.5 in, Body Width 1.77 in DC coil has same physical dimensions as AC coil AC control from 12V to 550V 50Hz, 600V 60Hz DC control from 12V to 220V 4-pole configurations IP20 finger and back-of-hand proof IEC Mini Control Relay, Current Rating 10 A, Contact Form 2NO/2NC, Contact Rating (DC) 2.5 A @ 24V, Coil Voltage 24V DC, Contact Rating (AC) 6 A @ 240V, Relay Style IEC, Electrical Connection Screw Terminal, Mounting Style DIN Rail, Power Consumption 2.6 W, IP Rating IP20, Frame Size 45 mm, NEMA Size Not Applicable, Compatible with Series XTRM Mini Control Relays, Maximum Operating Temperature 122 Degrees F, Frequency 60 Hz, Body Depth 2.05 in, Body Height 2.5 in, Body Width 1.77 in DC coil has same physical dimensions as AC coil AC control from 12V to 550V 50Hz, 600V 60Hz DC control from 12V to 220V 4-pole configurations IP20 finger and back-of-hand proof
