High Grade 12V 5V 24V 9V AC-DC Power Supply Buck Converter Step Down Module
$ 0.97
Description
High Grade 12V 5V 24V 9V AC-DC Power Supply Buck Converter Step Down Module. Output Current Range: 0A to 150mA, the peak current of 200mA. Input surge current: 20A (full load). Peak current :450mA. Output current:150mA. Output power: 3.6w. Input characteristics. Output Characteristics. High Grade 12V 5V 24V 9V AC-DC Power Supply Buck Converter Step Down Module 12V 400mA Input voltage :AC 85v ~ 265v ,50 / 60HZ Output voltage :DC12V Working Current :400mA Peak current :450mA Power: 4.5W Size:30*20*19mm 24V 150mA 1. Input voltage:AC85~265v 50/60HZ 2. Output voltage:DC24V (±0.2V) 3. Output current:150mA 4. Power:3.6W 5. PCB size:4*1.5*1.8cm Use environment: 1. Working temperature: -20 to 60℃ 2. Relative humidity: 40 to 90% RH Input characteristics 1. Input voltage range: 85VAC-265VAC 2. Input Current: 0.0273 (AC110V) 0.014 (AC220V) 3. Input surge current: 20A (full load) Output Characteristics 1. Output voltage range: 23.80~24.2V 2. Output Current Range: 0A to 150mA, the peak current of 200mA 3. Output power: 3.6w. 4. Output efficiency: 85% 5. Switching Overshoot: 10% 6. Output Rise Time: 100ms 5V 1A -Input voltage of AC 85 ~ 265v 50/60 HZ -Output voltage DC5V（±0.2V） -Output current 1000MA -Power 5w 5V 500mA Input voltage AC85 ~ 265v 50 / 60HZ Output voltage DC5V Operating current 500mA Dimensions Volume: LWH 32 * 18 * 13 (mm) 12V 500mA -Input voltage of AC 85 ~ 265v 50/60 HZ -Output voltage DC12V（±0.2V） -Output current 500mA 12V 450mA Input voltage: AC 85 ~ 265 v 50/60 hz or DC 100~ 370 v Input current: 0.0273A(AC110V) 0.014A(AC220V) Input Inrush Current: 20A Output voltage: DC 12V (+ / - 0.2 V) Output current 500 mA Operating temperature -20~60Deg.C Relative humidity 40-90%RH Output 12V, min current 0a, max current 500mA, peak current: 600mA, output range:11.80~12.1V, ripple wave: 150mV Output power:0-6W(DC current) Output efficiency: 80% Switch machine overshoot: MAX 10% Output voltage rise time: MAX 100MS Output over voltage: 11.8-12.1V, recovery:Lock, restart after recovery Output over power protection:YES ,recovery:Lock, restart after recovery Short-circuit protection: YES, automatic recovery after problem solved Temperature protection: YES,recovery:Lock, restart after recovery Overcurrent protection: YES,recovery:Lock, restart after recovery Size: 3 x 2 x1.8cm 5V 700mA Condition: brand new Quantity: 1pc Input voltage: AC 85 ~ 265 v 50/60 hz or DC 100~ 370 v Imput current: 0.0273A(AC110V) 0.014A(AC220V) Input Inrush Current: 20A Output voltage: DC 5V (+ / - 0.2 V) Output current 700 mA Power 3.5 W Operating temperature -20~60¡æ Relative humidity 40-90%RH Output 5V, min current 0a, max current 700mA, peak current: 800mA, output range: 4.8~5.2v, ripple wave: 60mV Output power:0-4W(DC current) Output efficiency: 80% Switch machine overshoot: MAX 10% Output voltage rise time: MAX 100MS Output over voltage: 4.8-5.2V, recovery:Lock, restart after recovery Output over power protection:YES ,recovery:Lock, restart after recovery Short-circuit protection: YES, automatic recovery after problem solved Temperature protection: YES,recovery:Lock, restart after recovery Overcurrent protection: YES,recovery:Lock, restart after recovery 5V 1.5A Input voltage AC 85 ~ 265v 50/60HZ or DC100v-370v Output voltage DC5V (± 0.2V) Output current 1500mA Power 7.5W Package included: 1PCS * Module Payment Shipping Policy Return About us Payment We accept Paypal as the payment method. We accept eBay address for shippment. Shipping Policy The default shipping is by China Post air mail/Hongkong air mail. Item will be shipped within 2-3 working days after full payment is received. The delivery to most of the countries will take 2-4 weeks, if there's no problem when pass through the customs. It will take about 30 days or more to some places. We accept paypal for payment We accept eBay address for shipping Return If you can't receive the product within 2 months (60 days), please contact with us,we promise to payback 100% of your money. We ensure our products work normally before post.If the products is broken before arrival to you,all you should do is taking a photo to show us our broken product.We promise to payback 100% of your money. About us We are a company based in China developing and manufacturing electronic development device , including electronic components ,camera module, camera lens , LCD modules and other development board for Raspberry pi,Arduino and other opensource hardware Platform We can also provide customized design and manufacture services according to your requirements.
