Lenze ACTech ESV552N04TXB VFD, 7.5hp, 400-480V, 3 Phase, NEMA 1

$ 264.35

Country of Origin: China Input Voltage: 460 V Enclosure: NEMA 1 Brand: Lenze Americas MPN: ESV552N04TXB Number Of Phases: 3-Phase Power Rating: 5.5 KW Model: ESV552N04TXB Rated Load: 7.5 HP

Description

Lenze ACTech ESV552N04TXB VFD, 7.5hp, 400-480V, 3 Phase, NEMA 1. Part Number:ESV552N04TXB. Enclosure NEMA: NEMA1. Input Phase: 3. Output Phase: 3. AC Line Option: Non-Switched. Encoder Input: None. Stop/Run: Key Pad. Enclosure IP: IP31. Part Number: ESV552N04TXB Manufacturer: Lenze SMV LENZE ESV552N04TXB 7.5HP NEMA1 IP31 SMVector Constant horsepower Frequency Inverter is the most common and cost effective drive enclosure for a wide range of applications including packaging, material handling / conveying, positive displacement pumping, and HVAC systems. Technical Details Series: SMV Output HP: 7.5 Output KW: 5.5 Input Voltage: 400-480 Input Phase: 3 Output Voltage: 400-480 Output Phase: 3 Output Amperage: 11.0 Enclosure NEMA: NEMA1 Enclosure IP: IP31 Stop/Run: Key Pad Direction Controls: Forward/Stop/Reverse Speed Potentiometer: None Encoder Input: None AC Line Option: Non-Switched RFI Filter Option: None Braking: Dynamic, DC Injection Optional Jog: None Environment: Indoor Brand: Lenze
