Merlin Gerin Compact NS100N Molded Case Circuit Breaker
$ 87.12
Description
Merlin Gerin Compact NS100N Molded Case Circuit Breaker. Compact NS100N. Application: Power distribution and circuit protection. Trip Unit Type: Thermal-Magnetic (Fixed thermal protection for overload, fixed magnetic protection for short-circuit). Compact NS. Brand: Merlin Gerin (a classic brand under Schneider Electric) Product Line: Compact NS Part Number (Reference Code): 29581 Device Short Name: Compact NS100N Application: Power distribution and circuit protection Schneider Electric Electrical Characteristics Number of Poles: 1 Pole (1P / 1t protected) Trip Unit Rating: 80 A at 40 °C (indicated by TM80D on the label) Trip Unit Type: Thermal-Magnetic (Fixed thermal protection for overload, fixed magnetic protection for short-circuit) Network Type: AC / DC compatible Network Frequency: 50/60 Hz Rated Insulation Voltage ( ): 750 V AC Rated Impulse Withstand Voltage ( ): 8 kV Rated Operational Voltage ( ): 277 V AC or 250 V DC Schneider Electric Breaking Capacity Specs (IEC 60947-2) 25 kA Icu at 220/240 V AC 25 kA Icu at 277 V AC 50 kA Icu at 250 V DC 50 kA Icu at 48/125 V DC Rated Service Breaking Capacity ( ): 100% of (25 kA for AC network ratings) Schneider Electric Standards & Environment Compliance Standard: IEC 60947-2 Suitability for Isolation: Yes Pollution Degree: 3 Origin: Made in France (as printed on the bottom label segment)
