NEW Hubbell Double Pole Toggle Switch CSB2201 Commercial Grade 20A 120/277V AC
$ 2.25
Description
NEW Hubbell Double Pole Toggle Switch CSB2201 Commercial Grade 20A 120/277V AC. Toggle Material - Nylon. Double Pole. Ground Screw - Brass (Green). Catalog Number. Maximum continuous 75°C and minimum -40°C without Impact. Withstands 1500V AC minimum for 1 minute. Temperature Rise - Max. NEW Hubbell Double Pole Toggle Switch CSB2201 Commercial Grade 20A 120/277V AC Back and Side Wired. Ships free here in the US. General Catalog Number CSB220I Color Ivory EU RoHS Indicator Yes Item Type Material Nylon Operating Temperature Maximum continuous 75°C and minimum -40°C without Impact Specifications Auto Grounding Mounting Bridge - Zinc Plated Steel Base Material - Thermoplastic, Black Contacts - Silver Alloy Ground Screw - Brass (Green) Terminal Screws - Brass Toggle Material - Nylon Top Material - Thermoplastic, Gray Style Double Pole Type Toggle UPC 783585154138 Dimensions Dimensions 4.18 in x 1.49 in x 1.83 in Height 1.83 in Length 4.18 in Weight 0.15 lb Width 1.49 in Electrical Ratings Amperage Rating 20 A Connectivity Back and Side Wired Current Rating 20 A Dielectric Strength Withstands 1500V AC minimum for 1 minute Temperature Rise - Max. 30°C maximum at rated current Voltage Rating 120-277 VAC Conductor Related Number Of Poles Double Pole Wire Size #14 AWG to #10 AWG Certifications And Compliance EU RoHS Indicator Yes Industry Standard(s) UL Listed Standards - RoHS Compliance Status CM Operational Operating Temperature Maximum continuous 75°C and minimum -40°C without Impact Configuration Number Of Poles Double Pole
