Schneider LC1D12M7 - Contactor TeSys D 3P AC3 12A 220VAC coil - Made In France-image

Schneider LC1D12M7 - Contactor TeSys D 3P AC3 12A 220VAC coil - Made In France

$ 19.01

Type: CONTACTOR Model: LC1D12M7 Number in Pack: 1 Current Rating: 12A Brand: Schneider Electric Maximum Amperage: 12A Number of Poles: 3P Packaging: Box Interruption Type: AC3 Country of Origin: France Unit Qty: 1 Voltage: 220VAC

Description

Schneider LC1D12M7 - Contactor TeSys D 3P AC3 12A 220VAC coil - Made In France. TeSys D contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3/3e (5.5kW@400V). It provides a 220V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh). TeSys D contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3/3e (5.5kW@400V). It provides a 220V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
