Square D LLA36400U44X - MCCB 400A 3P 600VAC 50kA Mic. 6.3A ABC, Circuit Breaker-image

Square D LLA36400U44X - MCCB 400A 3P 600VAC 50kA Mic. 6.3A ABC, Circuit Breaker

$ 997.92

Number of Poles: 3P Voltage: 600VAC Maximum Amperage: 400A Model: LLA36400U44X Number in Pack: 1 Current Rating: 400A Packaging: Original Box Brand: Square D by Schneider Electric Type: Molded Case Circuit Breaker Breaking Capacity: 50kA Mounting Style: I‑Line style plug‑in Interruption Type: Micrologic 6.3A Unit Qty: 1

Description

PowerPacT L-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT L-Frame circuit breakers are available with electronic trip units. All PowerPacT L-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT L circuit breakers are available in 3 and 4-pole unit mount, I-Line, and drawout constructions. This PowerPacT L, 400A, 3 pole, circuit breaker has an interrupting rating of 50kA at 600VAC. This circuit breaker provides MicroLogic Ammeter with a 6.3A trip unit and an LSIG function. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. PowerPacT L circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
